SR480T

Integrated machine Refrigerated Units

SR-480T refrigeration unit is a product specially developed for light truck 4.2m refrigerated truck, with beautiful appearance and strong cooling capacity. The evaporator does not occupy the space of the box, increasing the volume of the box and the cargo capacity.

20211202085256-sr480t-condenser-appearance-1

20211202085303-sr480t-evaporator-appearance-5

20211202085300-sr480t-condenser-appearance-3

20211202085259-sr480t-condenser-appearance-2

20211202085301-sr480t-evaporator-appearance-4

Discover more

Instruction Manual

Product Brochure

The high-quality and reliable SR-480T truck refrigeration unit is a first-class refrigerated truck cooling system. Provide the perfect transportation temperature control solution for your refrigerated truck. Fast cooling speed: the ambient temperature is 30°C, and the temperature drops to 0°C within 30 minutes; the ambient temperature is 30°C, and the temperature drops to -18°C within 60 minutes;

SR-500 refrigerated truck refrigeration unit is a split structure, composed of condenser, evaporator, compressor, control panel, connecting pipes and wiring harness. The compressor is directly driven by the vehicle engine; the refrigeration unit is suitable for 4.2m refrigerated trucks, the best transportation temperature is controlled at -20℃ or 0℃, and the transport volume of the refrigerated truck is 20-30m³.

SR-500 truck refrigeration unit has a fast cooling speed: the ambient temperature is 30℃, and it will drop to 0℃ in 30 minutes; the ambient temperature is 30℃, and the temperature will drop to -18℃ in 60 minutes; if you are looking for a high temperature for a truck of 18~25m³ For quality freezers, SNEWWANG SR-500 will be a better choice.

Parameters of refrigeration unit
Model	SR-480T
Applicable box volume	14-17m³
temperature range	-18℃~+15℃
Cooling capacity	0℃/+30℃	4850
	-18℃/+30℃	2500
Voltage	DC12V/DC24V(Optional)
Electric current	44A@12V
	26A@24V
Drive mode	Dependent
Compressor	TM16
Refrigerant	R404
Refrigerant charge	2.2kg
Defrost method	Hot gas defrost
Condenser assembly	Size mm（length * width * height）	1850570680
	Weight (kg)	82
Condenser fan	Quantity	2
	Total air volume	4000m³/h
Evaporator fan	Quantity	3
	Total air volume	3600m³/h

Product Details

Key Features

The integrated structure does not occupy the internal space of the box, which is convenient for loading and hanging meat, etc.;
The evaporative heat exchanger has a large volume and a large air volume to ensure efficient heat exchange capacity and sufficient cold transfer;
The controller adopts light-touch temperature and air volume adjustment, and the temperature adjustment range is wide (-25°C to +30°C);
The industry's original double-sealing technology, the leakage of the system is less than 3 grams per year, and long-term reliable operation without leakage;
The electronic control system has multiple detections and multiple protections to ensure the safety and reliability of the control system;
The American AMP/Delph waterproof connector has a pulling force greater than 180N/M, sealed and waterproof, preventing poor contact, thickening the wire, and high temperature without heating;
Danfoss (DANFOSS) control valve, precise control, low failure rate;
